Serial-Based M&C using the CLC-10 MN-CLC10
3–19
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to Query
(Target to
Controller)
Global Amplifier
Configuration
GAC= 43 bytes Command or Query.
Sets or returns the global status of the BUC/SSPA with a semicolon delimited string in the form a;b;cc.cc;dd.dd;
e; fffff;g;hh;I;j;k;l;m;n;o where:
a=redundancy mode (ESW)
b=online status (ONL)
cc.cc=Attenuation Offset (AOF)
dd.dd=Customer Attenuation(ATT)
e=Auto Fault Recovery (AFR)
fffff=Unit Alarm Mask (MSK)
g=LNB Current Source (LCS)
hh=LNB Current Window (LCW)
i=LNB Current Window Enable (CWE)
j=Enable Statistics Averaging (ESA)
k=Set Statistics Interval (SSI)
l=Enable Statistics Logging (ESL)
m=Auxiliary Mute (AUX)
n=user mute state (MUT)
o=RF power amplifier state (AMP)
Example (set GAC): GAC=a;b;cc.cc;dd.dd;e;fffff;g;hh;I;j;k;l;m;n;o;’cr’
GAC=
GAC*
GAC?
GAC#
GAC? GAC=x….x
(See Description of
Arguments)
Initialize Events
Pointer
IEP= None Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the stored events log.
Example: <1/IEP=’cr’
>0001/IEP=’cr’lf
IEP=
IEP?
IEP*
N/A N/A
Software Image IMG= 1 byte Command or Query.
Sets or returns the current active software image in the form x, where:
1=Bulk Image # 1 currently active
2=Bulk Image # 2 currently active
Note: if you send the IMG command, and then query the IMG value the numbers may not be equal because the
command tells the firmware which image to boot from at the next bootup, and the query reports the image that the
firmware booted from on the last bootup.
Examples:
<1/IMG=1’cr’ (instructs the unit to load firmware from image #1 at the next reset / power up).
<1/IMG?’cr’ (queries the image number that the firmware loaded during bootup)
IMG=
IMG?
IMG*
IMG#
IMG? IMG=x
(See Description of
Arguments)
