CLC-10 Comtech LPOD Controller Handheld Terminal M&C Accessory Revision 3
Serial-Based M&C using the CLC-10 MN-CLC10
3–16
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to Query
(Target to
Controller)
Concise
Maintenance
Status
N/A 95 bytes Query only.
This is the concise version of the RMS command. Returns the Maintenance status of the unit, response is
semicolon delimited, in the form aaa.a;bbb.b;ccc.c;ddd.d;eee.e;fff.f;ggg.g;hhh.h;iii.i;jjj.j;kkk.k;lll.l;mmm.m;nnn.n;
ooo.o;ppp.p;qqq.q;rrr.r;sss.s;ttt.t where:
aaa.a=P24V1
bbb.b=P24V2
ccc.c=LNBVT (see Note)
ddd.d=P13VT
eee.e=P10V1
fff.f=A10V1
ggg.g=A10V2 (see Note)
hhh.h=P7V8T
iii.i=P5V8T
jjj.j=P2V5T
kkk.k=P1V2T
lll.l=N5V8T
mmm.m=FANR1 (see Note)
nnn.n=FANR2 (see Note)
ooo.o=BUCVT (see Note)
ppp.p=FWPWR
qqq.q=REFVT (see Note)
rrr.r=LNBCS (see Note)
sss.s=ATEMP
ttt.t=OTEMP (see Note)
Note: ccc.c, ggg.g, mmm.m, nnn.n, ooo.o, qqq.q, rrr.r, and ttt.t will appear if the appropriate model/options have
been selected/installed. Otherwise, the unused fields will display XXXXX.
Example: <1/CMS?
>0001/CMS=aaa.a;bbb.b;ccc.c;ddd.d;eee.e;fff.f;ggg.g;hhh.h;iii.i;jjj.j;kkk.k;lll.l;mmm.m;nnn.n;ooo.o;ppp.p;qqq.q;
rrr.r;sss.s;ttt.t’cr’’lf’
CMS= CMS? CMS=x….x
(See Description of
Arguments)
LNB Current
Window Enable
CWE= 1 bytes Command or Query.
Sets or returns the LNB current window alarm in the form x, where:
0=Disabled (default value)
1=Enabled (see Note)
Note: If disabled, the LCW value will be retained, but unused.
Example: <1/CWE=0’cr’
>0001/CWE=’cr’’lf’
CWE =
CWE?
CWE *
CWE? CWE =x
(See Description of
Arguments)
