3.1.2 LED Indicators
LED Color Description
LNA 1 FAULT Red LED Illuminates with a fault in LNA/LNB 1.
LNA 2 FAULT Red LED Illuminates with a fault in LNA/LNB 2.
BACKUP LNA
FAULT
Red LED Illuminates with a fault in backup LNA/LNB. (See note)
LNA 1 ON LINE Green
LED
Illuminates when LNA/LNB 1 is on line.
LNA 2 ON LINE Green
LED
Illuminates when LNA/LNB 2 is on line.
BACKUP ON 1
Green
LED
Illuminates when backup LNA/LNB is on Pos 1. (See note)
BACKUP ON 2
Green
LED
Illuminates when backup LNA/LNB is on Pos 2. (See note)
AUTO
Green
LED
Illuminates when unit is in auto mode.
MANUAL
Amber
LED
Illuminates when unit is in manual mode.
PRIORITY 1 Green
LED
Illuminates when the unit considers LNA/LNB 1 to be a priority. (See Note)
PRIORITY 2 Green
LED
Illuminates when the unit considers LNA/LNB 2 to be a priority. (See note)
REMOTE
Green
LED
Illuminates when the unit is in remote mode.
LOCAL
Amber
LED
Illuminates when unit is in local mode.
PS1 Green
LED
Illuminates when output power of power supply 1 is greater than 14V. Also denotes voltage
present at PS1, when using a Wave Guide (WG) DC Switch.
PS2 Green
LED
Illuminates when output power of power supply 2 is greater than 14V. Also denotes voltage
present at PS2, when using a Wave Guide (WG) DC Switch.
Note: Applies to RC-1260 systems only (1:2 systems).
