Introduction Revision 1
RC-1160 RC-1260 Redundancy Switch Controllers MN-RC1160RC1260
1–5
1.2 Specifications
Parameter Specification
Power Input 90 to 240 VAC, 47 to 63 Hz, less than 40W Input protected by 2.0A circuit breaker
Nominal current 0.65A (standard)
Power Output 14 VDC, 0.5A per LNA/LNB (standard) 14 VDC, 600 mA per LNA/LNB (optional) Each
outlet protected by a current-limiting regulator.
Physical Dimensions: Depth Height Width (Front
Panel) Width (Chassis)
16” (40.64 cm) 1 3/4” (4.44 cm) 19” (48.26 cm) 16.5” (41.91 cm)
Weight 5 lb. (2.27 Kg)
Environmental: Operating Temperature Storage
Temperature Humidity
+10 to +50°C (+50 to +122°F) -40 to +100°C (-104 to 212°F) 5 to 85%, non-
condensing
1.2.1 Front Panel Controls
Parameter Specification
LNA 1 ON LINE Press the switch to place the LNA/LNB 1 on line.
LNA 2 ON LINE Press the switch to place the LNA/LNB 2 on line.
AUTO SW Press the switch to the left to place the unit in the Automatic switch-over mode.
MANUAL SW Press the switch to the right to place the unit in Manual mode.
REMOTE SW Press the switch to the left to place the unit in Remote mode.
LOCAL SW Press the switch to the right to place the unit in Local mode.
AUDIO ALARM DISABLE Toggle the switch to disable the audio alarm.
LAMP TEST SW Press the switch to activate all LEDs.
BACKUP 1 * Press the switch to force the backup LNA/LNB to go online for LNA/LNB 1.
BACKUP 2 * Press the switch to force the backup LNA/LNB to go online for LNA/LNB 2.
PRIORITY 1 SW * Press the switch to the left to operate with LNA/LNB 1 as priority.
PRIORITY 2 SW * Press the switch to the right to operate with LNA/LNB 2 as priority.
Applies to the RC-1260 only (1:2 systems).
1.2.2 Rear Panel Controls
Parameter Specification
AC POWER A Toggle switch and 2A circuit breaker. Allows the primary power to be turned ON or OFF.
AC POWER B Toggle switch and 2A circuit breaker. Allows the secondary power to be turned ON or OFF.
CALIBRATION SW Performs calibration of the LNA/LNB currents.
