Operation Revision 1
RC-1160 RC-1260 Redundancy Switch Controllers MN-RC1160RC1260
3–1
Chapter 3. OPERATION
This chapter describes the following:
• Status and control
• Modes of operation
• Calibration
• Internal adjustments and switches
Before operating the unit from the front panel, check to ensure that the installation is complete. Check the
connections from the waveguide switch indicators (shown in Chapter 1).
NOTE: The unit will not be damaged if the waveguide switch indicator connections are
not made. However, the online indicators will be erroneous.
3.1 Status and Control
This section describes the various controls and status indicators for the switch controller. Refer to Figure 3-1,
Figure 3-2, and Figure 3-3 for switch and indicator locations.
