1.2.3 Indicators
Note: Applies to RC-1260 only (1:2 systems).
Parameters
Specification
LNA 1 FAULT
Red LED
Illuminates with a fault in LNA/LNB 1.
LNA 2 FAULT
Red LED
Illuminates with a fault in LNA/LNB 2.
BACKUP LNA
FAULT
Red LED
Illuminates with a fault in backup LNA/LNB. (See note)
LNA 1 ONLINE
Green LED
Illuminates when LNA/LNB 1 is online.
LNA 2 ONLINE
Green LED
Illuminates when LNA/LNB 2 is online.
BACKUP ON 1
Green LED
Illuminates when backup LNA/LNB is on Pos 1. (See note)
BACKUP ON 2
Green LED
Illuminates when backup LNA/LNB is on Pos 2. (See note)
AUTO
Green LED
Illuminates when unit is in auto mode.
MANUAL
Amber LED
Illuminates when unit is in manual mode.
PRIORITY 1
Green LED
Illuminates when the unit considers LNA/LNB 1 to be a priority. (See note)
PRIORITY 2
Green LED
Illuminates when the unit considers LNA/LNB 2 to be a priority. (See note)
REMOTE
Green LED
Illuminates when the unit is in remote mode.
LOCAL
Amber LED
Illuminates when unit is in local mode.
PS1
Green LED
Illuminates when output voltage of power supply 1 is greater than 14V. Also denotes voltage
present at PS1, when using a Wave Guide (WG) DC Switch.
PS2
Green LED
Illuminates when output voltage of power supply 2 is greater than 14V. Also denotes voltage
present at PS2, when using a Wave Guide (WG) DC Switch.
1.2.4 Internal Switches
Switch
Specification
NORMAL/MAINT Toggle Allows service technician to direct the +15V power directly to the LNA/LNB outputs (SW1).
NORMAL/WIDE
Slide
On the logic PWB to change the sensitivity of the current window (SW1).
1.2.5 Internal Indicators
Indicator
LED
Specification
MAINT MODE
Red
Illuminates when the maintenance switch (SW1) is in the maintenance position. Located on the
Maint/Power PWB.
+15V1
Green Illuminates when +15V is present from PS1.
+15V2
Green Illuminates when +15V is present from PS2.
+5V
Green Illuminates when +5V is present.
SUMMARY
FAULT
Red
Illuminates when any fault is present.
