MIDAS 4.2 Basic Configuration, Rev. 1

2–54

Setup and Operation

Click the Add button to display the Enter Circuit ID window, which allows the operator to
create a new Predefined Circuit.

C

C

i

i

r

r

c

c

u

u

i

i

t

t

I

I

D

D

This is the unique number given to each Circuit ID, which must be a number in
the range of 1 through 4998.

C

C

i

i

r

r

c

c

u

u

i

i

t

t

T

T

y

y

p

p

e

e

• Data – this button selects a Predefined Data Circuit.

• Video – this button selects a predefined Video Circuit.

Enter the Circuit ID number, select the desired Circuit type by clicking the appropriate
button, and click OK to accept. The Data Circuit Details window will be displayed, which
allows the operator to configure the various Predefined Connection parameters.
