MIDAS 4.2 Basic Configuration, Rev. 1
2–22 Setup and Operation
O O c c c c u u p p a a n n c c y y G G r r a a p p h h
S S t t a a t t u u s s I I n n d d i i c c a a t t o o r r s s
To move a status indicator, position the mouse cursor over the title (but not
near a divider). Drag the indicator to a new position.
To alter the width of a status indicator column, position the mouse cursor over
a vertical separator. When the cursor changes to a sizing cursor, drag the
separator to change the width as desired.
Start Time The date and time when the statistics began accumulating.
Chn Size Transponder channel size
Transponder Total number of transponder channels
Managed Chn Number of channels being managed by the Controller Server
Free Chn Number and percentage of managed channels not allocated (in use by
active calls)
Allocated Chn Number and percentage of managed channels allocated to active calls
Ctrl Link Chn Number and percentage of channels in use for control links
Managed Chn-Mins Number of channels managed per minute
Allocated Chn-Mins Number and percentage of channels allocated per minute
Req Links Number of allocation requests
Granted Links Number and percentage of allocation requests granted
Blocked Links Number and percentage of allocations blocked
Preempted Links Number and percentage of allocations preempted
Requested Chn Number of channels requested
Granted Chn Number and percentage of channel requests granted
Blocked Chn Number and percentage of channels blocked
Preempted Chn Number and percentage of channels preempted
Granted Overflow Links Number of overflow links granted
Granted Overflow Chn Number of overflow channels granted
