MIDAS 4.2 Basic Configuration Rev. 1
Maintenance Menu A–5
Bandwidth = 2.4 MHz , the beginning and end of your space segment is found
by the following formula:
RX IF Center – 1/2 bandwidth = Space Segment Beginning IF
RX IF Center + 1/2 MHz = Space Segment Ending IF
82.5 MHz – 1.2 MHz = 81.3 MHz
82.5 MHz + 1.2 MHz = 83.7 MHz
1. Select Space Segment, view IF.
2. Right click on any area (yellow area) in Free Space.
3. Select Add Bandwidth.
4. Select IF.
5. Add Start 81.300000 and End 83.700000.
6. Close Space Segment window.
7. Observe Close Channel window is displayed.
C C o o n n t t r r o o l l C C h h a a n n n n e e l l S S e e t t u u p p
