Delete Bandwidth When the operator clicks on the desired allocated area in the Space Segment grid, this opens the Delete
Bandwidth window, which allows allocated bandwidth to be deleted and returned to the Free pool or
Public pool.
Show By Data Rate This toggles the display mode
When the button is selected, the graph shows calls by Circuit Type; when the button is not selected, calls
are shown by Data Rate.
In each display mode, separate color codes indicate the circuit types or data rates. In Circuit Type mode,
the following circuit types are shown: Free, Owned, Control Channel, Data, ISDideo
The colors for each of these types may be configured (refer to the Options menu).
Reset Statistics This prompts the operator to reset the cumulative statistics.
Edit Legend This opens the Options window with the properties page for the selected legend item.
Add Legend This creates a new default legend item and then opens the Options window, so that the default settings
can be changed.
Delete Legend This deletes the selected legend item from the list.
Use the vertical scroll bar to see additional bandwidth segments.
Use the horizontal scroll bar to see additional statistics.
To alter the width of a column or height of a row, position the mouse cursor
over the separator near the column or row label. When the cursor changes to a
sizing cursor, drag the separator to change the width or height.
