Appendix B OMS11 1:1 Redundancy Switch
B-8 TM133 – Rev. 1.1
Opcode <2083h> Query OMS11 Backup Configuration
Query Response Data Field (1 byte):
<1>
Backup Configuration 0 = Modem (Coupled)
1 = Mod Only
2 = Demod Only
3 = Mod/Demod (Uncoupled)
Opcode <2084h>
Query OMS11 Backup Mode
Query Response Data Field (1 byte):
<1>
Backup Mode 0 = Manual
1 = Automatic
2 =
Opcode <2284h>
Command OMS11 Backup Mode
Command Data Field (1 byte):
<1>
Backup Mode 0 = Manual
1 = Automatic
Opcode <2085h>
Query OMS11 Backup State
Query Response Data Field (2 bytes):
<1>
Mod Backup state 0 = A online
1 = B online
2 =
<1>
Demod Backup State 0 = A online
1 = B Online
2 =
Opcode <2285h>
Command OMS11 Force Manual Backup
Command Data Field (2 bytes):
<1>
Mod Backup State 0 = A online
1 = B online
<1>
Demod Backup State 0 = A online
1 = B online
Opcode <2086h>
Query OMS11 Switch Delays
Query Response Data Field (8 Bytes):
<1>
Switch Delay Mod Fault MSB
<1> Switch Delay Mod Fault LSB
<1> Switch Delay Mod NoFault MSB
<1> Switch Delay Mod NoFault LSB
<1> Switch Delay Demod Fault MSB
<1> Switch Delay Demod Fault LSB
<1> Switch Delay Demod NoFault MSB
<1> Switch Delay Demod NoFault LSB
Opcode <2286h>
Command OMS11 Switch Delays
Command Data Field (8 Bytes):
<1>
Switch Delay Mod Fault MSB
<1> Switch Delay Mod Fault LSB
<1> Switch Delay Mod NoFault MSB
<1> Switch Delay Mod NoFault LSB
<1> Switch Delay Demod Fault MSB
<1> Switch Delay Demod Fault LSB
<1> Switch Delay Demod NoFault MSB
