Connector Pinouts
OMS11 1:1 Redundancy Switch
TM133 – Rev. 1.1
5-14
5.9
Modem B Remote/Terminal/Fault Port on the OMS11 (J14)
This port provides Fault status and RS485 Communications to the OMS11 from the OM20
(Modem B). This port utilizes an 18-Pin D38999/24FD18PN Connector. Refer to Table 5-13 for
the pinout information.
Table 5-13 Remote/Terminal/Fault Connector (J14)
Pin No.
Signal Name
Signal
Direction
A
Receive Data RS-232
RX-232
---
B
Transmit Data RS-232
TX-232
---
C
No Connect
---
---
D
Transmit Data RS-485 (+)
TX-485-B
Output
E
Transmit Data RS-485 (-)
TX-485-A
Output
F
Receive Data RS-485 (+)
RX-485-B
Input
G
Receive Data RS-485 (-)
RX-485-A
Input
H
Ground
GND
---
J
Mod Fault – Common
MF-C
---
K
Mod Fault – NC
MF-NC
---
L
Mod Fault – NO
MF-NO
---
M
Demod Fault - Common
DF-C
---
N
Demod Fault – NO
DF-NO
---
S
Demod Fault – NC
DF-NC
---
R
Ground
GND
---
U
No Connect
---
---
P
No Connect
---
---
T
No Connect
---
---
5.10 TX & RX Waveguide Switch Interface (J5 & J9)
These ports provide 48Volts for switching the RX and TX Waveguide switches. For TX
waveguide switching, connect the CAR5904 cable between the J5 of the OMS11 to the TX
waveguide Switch. For RX waveguide switching, connect the CAR5904 cable between the J9 of
the OMS11. The chart below identifies the J5 & J9 pinouts on the OMS11 and the mating
connector pinout for a Sector Microwave Switch. Connector information and pinout descriptions
are identified below. Refer to Table 5-14 and Figure 5-3. CAR5904 is supplied by Radyne when
waveguide switching hardware is supplied by Radyne.
