Comtech EF Data OMS11 User Manual
Page 60
OMS11 1:1 Redundancy Switch
Appendix A
TM133 – Rev. 1.1
A-
3
When Jumpers are set for SOFT, this allows user to set the Baud and Unit
Addresses remotely via the terminal port.
Figure A3 Illustrates how to configure the Dip Switches for RS232 Data on an OMS11.
Figure A3. DIP Switch on the RS232 Driver
Figure A4 Illustrates how to configure the Dip Switches for G.703 Unbalanced data on an OMS11
with Universal Data Interface.
Figure A4. DIP Switch on the G.703 Driver
