Connector Pinouts
OMS11 1:1 Redundancy Switch
TM133 – Rev. 1.1
5-2
5.1
LED Indicators
There are nine (9) Light Emitting Diodes (LED’S) on the front of the unit. LEDs identify status of
Modem A, Modem B and OMS11. LEDs for Modem A and Modem B include Modems Online
Status and Fault Status. LEDs for the OMS11 include Power 1 Status, Power 2 Status, OMS11
Fault status, Auto Mode and Manual Mode. When power is supplied to the unit and the power
supply is functioning normally, this LED will be Green. Refer to Table 5-2. LED’s for pin-out
descriptions.
Table 5-2. LED’s
Label
Description
Location
ONLINE
Modem online
MODEM A
FAULT
Modem has a fault
MODEM A
AUTO
Auto Mode selected
OMS11
MANUAL
Manual Mode selected
OMS11
FAULT
OMS 11 has a fault
OMS11
PWR 1
Power 1 status
OMS11
PWR 2
Power 2 status
OMS11
ONLINE
Modem online
MODEM B
FAULT
Modem has a fault
MODEM B
5.2
Power Input
5.2.1 AC Power Input (J6, J10)
AC Inputs are located on connector J6 and J10 of the OMS11. The auto-ranging universal power
supply input allows for the connection of AC power to the port between the range of 100 – 240
VAC and 50 – 60 Hz. Power consumption for the unit is 1.0A (OMS11) only. An external chassis
ground post is located on the OMS11. The ground post is a #10-32 threaded stud that is used for
external grounding and should not be used to ground the AC power Source on J6 and J10. The
mating power connector is a 4-pin socket MFG P/N (D38999/24FC4SN) connecter. The mating
connector supplied with the unit.
Refer to Table 5-3 AC Powerfor the connector pinouts.
Table 5-3 AC Power
A
Line (L1)
B
Neutral (L2)
C
Ground
5.2.2 DC Power Input (J6, J10) (Optional)
An Optional DC Power Input is available for the OMS11. DC Inputs are located on connector J6
AND J10 of the OMS11. The unit may be powered from a 44 – 56 VDC source with maximum
power consumption is 1.5 amps. This port is a 4-pin plug MFG P/N (D38999/24FC4PN)
connector. The mating connector supplied with the unit. Refer to Table 5-4. DC Power for the
connector pinouts.
