Comtech EF Data OMS11 User Manual
Page 23
User Interfaces
OMS11 1:1 Redundancy Switch
TM133 – Rev. 1.1
3-2
SELECT Modem A
(Pushbutton)
--------------------
Allows the operator to select
Modem A
SELECT Modem B
(Pushbutton)
--------------------
Allows the operator to select
Modem B
Modem A Controls and Indicators
Online LED
Indicates Modem A is
online
LED illuminates Green for Online
Fault LED
The OMS11 has received
a fault from Modem A
LED illuminates Red for Fault
Modem B Controls and Indicators
Online LED
Indicates Modem B is
online
LED illuminates Green for Online
Fault LED
The OMS11 has received
a fault from Modem B
LED illuminates Red for Fault
