Cable & Connector Configurations
D-2 Falcon ® 4400 Series with Windows Mobile ®
Serial Cable
Figure D-2 illustrates the connector configuration of the Serial cable for the
Falcon.
Figure D-2. Serial Connector Configurations
Printer Cable
Figure D-3 illustrates the connector configuration of the Printer cable for the
Falcon.
Figure D-3. Printer Connector Configurations
PC End
Falcon End
72 inches +/- 2
HR
S
Printer Cable End
Falcon End
HR
S
6 inches +/- 1
