Group
Name
CmdResp Description
Read
/
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
AUDIO_MASTER_VOLUME
AV AV Output Master volume
Rd/Wr0
255 255
0 = mute, 32 = -18dB , 255 = 0dB
0 = Main output
1 = Preview
output
AUDIO_MODE
Am Am Audio stero mode
Rd/Wr0
1
1
0 = mono
1 = Stereo
0 = Main output
1 = Preview
output
AUDIO_DELAY
AD AD Delay between audio and video Rd/Wr0
80
0
0 = no delay
500ms = max delay
0 = Main output
1 = Preview
output
AUDIO_AUTO_DELAY
Ae Ae
Automatic audio delay
Rd/Wr0
1
1
0 = réglage manuel du Delay, 1 =
reglage automatique du delay
AUDIO_SDI_CHAN_LEFT
Ac Ac
ID of the Sdi channel to
desembed for left channel
Rd/Wr0
15
0
0 = Group A – Channel 1
1 = Group A – Channel 2
2 = Group A – Channel 3
3 = Group A – Channel 4
4 = Group B – Channel 1
5 = Group B – Channel 2
6 = Group B – Channel 3
7 = Group B – Channel 4
8 = Group C – Channel 1
9 = Group C – Channel 2
10 = Group C – Channel 3
11 = Group C – Channel 4
12 = Group D – Channel 1
13 = Group D – Channel 2
14 = Group D – Channel 3
15 = Group D – Channel 4
10 = Channel
11 – SDI 1
11 = Channel
11 – SDI 2
12 = Channel
11 – SDI 3
13 = Channel
12 – SDI 4
