Analog Way PULSE LE - Ref. PLS200 Programmer's Guide - Manual (Page 10)

10
Group
Name CmdResp Description
Read
/
Write
Min
Value Max
value Default
value
Values Index #1 Index #2
IN_TYPE iK iK Input signal type Rd/Wr0 17 13
0 = SDTV Composite
1 = SDTV Y/C
2 = SDTV/EDTV/HDTV RGBS
TTL/Analog
3 = SDTV/EDTV/HDTV RGB
SOG
4 = SDTV/EDTV/HDTV YUV
5 = Computer SOG
6 = Computer H&V or Composite
(TTL/Analog)
7 = Computer B&W
8 = DVI-D EDTV/HDTV RGB 16-
235
9 = DVI-D EDTV/HDTV YUV
10 = DVI-D Computer RGB 0-
255
11 = DVI-D Computer RGB 16-
235
12 = SDI SDTV/HDTV
13 = Analog Computer,
separated H&V synchro
14 = Analog Computer,
composite TTL synchro
15 = Analog Computer,
composite analog synchro
16 = Analog RGB video,
composite TTL synchro
17 = Analog RGB video,
composite analog synchro
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_SYNC_LOAD il il Analog H sync load Rd/Wr0 1 0
0 = Hi-Z
1 = 75 ohm loaded
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
