47
Group
Name CmdResp Description
Read
/
Write
Min
Value Max
value Default
value
Values Index #1 Index #2
REFLOCKSTATUS Xl Xl Framelock locked status Rd 0 1 0 1 = locked
0 = Main output
1 = Preview
output
LAN
LANENABLE ne ne LAN enable Rd/Wr0 1 0
0 = Enable RS232 ( disable
LAN )
1 = Enable LAN ( disable
RS232 )
LANRESET nr nr LAN factory parameters reset Rd/Wr0 1 0 Auto reset
LANSTORE ns ns LAN parameters update Rd/Wr0 1 0 Auto reset
LANIP nw nw LAN devices addresses Rd/Wr0 255 192 IP : 0 to 255
0 = Device
1 = Remote
2 = Gateway
0 = IP address
high byte
1 = IP address
mid high byte
2 = IP address
mid low high
byte
3 = IP address
low byte
LANPORT np np LAN port numbers Rd/Wr0 6553510500
Local port : 10000 à 10999
Remote port : 0 à 65500
0 = Device
1 = Remote
2 = Gateway
LANNETMASK nk nk LAN netmask Rd/Wr0 24 8 Number of 0bits from the right
LANPROTOCOL nt nt LAN protocol Rd/Wr0 1 1
0 = UDP Protocol
1 = TCP protocol
2 = AMX Protocol
