Analog Way PULSE LE - Ref. PLS200 Programmer's Guide User Manual
Page 26
26
Group
Name
CmdResp Description
Read
/
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
SET_CROP_WIN_SIZE_V
SL SL
Vertical cropping
Rd/Wr0
589810
Percent = 65535 = 100%
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_ASPECT_RATIO_IN
si
si
Input image aspect ratio
Rd/Wr0
4
0
0 = 4/3 Fullscreen
1 = 4/3 with 16/9 content + black
stripes
2 = 4/3 with 2.35 content + black
stripes
3 = 4/3 with 16/9 content without
black stripes
4 = 19/9 with 4/3 content + black
stripes
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_ASPECT_RATIO_OUT
so
so
Output image aspect ratio
Rd/Wr0
3
1
0 = Distorted, input aspect ratio
not preserved
1 = Not distorted, black bands
added
2 = Not distorted, no black bands
added
3 = Not distorted and no scaling
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_OVER_SCAN
sO sO
input image
Overscan/Underscan
Rd/Wr0
1
1
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
