EDID
EDID_FORMAT EF EF EDID preferred format Rd/Wr0 21 0
0 = VGA
1 = 800x480
2 = WVGA
3 = SVGA
4 = 720pRGB
5 = XGA
6 = WXGA
7 = SWXGA
8 = 800pRGB
9 = 1152x864
10 = 900pRGB
11 = 1600x900
12 = 960pRGB
13 = SXGA
14 = 1360x1024
15 = SXGA+
16 = WSXGA+
17 = 1080pRGB
18 = 2K
19 = UXGA
20 = WUXGA
21 = Custom
0 = Analog
input 1
1 = Analog
input 2
3 = DVI-D input
1
4 = DVI-D input
2
EDID_RATE ER ER
EDID preferred frame
frequency
Rd/Wr0 5 0
0 = 50 Hz
1 = 60 Hz
2 = 72 Hz
3 = 75 Hz
4 = 85 Hz
5 = Custom
0 = Analog
input 1
1 = Analog
input 2
3 = DVI-D input
1
4 = DVI-D input
2
EDID_REQUEST ES ES Request for an EDID Rd/Wr0 2 0
0 = EDID is ready
1 = EDID saving
2 = EDID reading
0 = Analog
input 1
1 = Analog
input 2
3 = DVI-D input
1
4 = DVI-D input
2
