32
Group
Name CmdResp Description
Read
/
Write
Min
Value Max
value Default
value
Values Index #1 Index #2
PE_SIZE_V pS pS
Layer V size on output screen
(without borders)
Rd/Wr0 655351200
Unit = pixels (Max=16x2048 =
32768)
0 = Current
preset
1 = Next preset
2 = Previous
preset
3 = Memory
Preset 1
4 = Memory
Preset 2
5 = Memory
Preset 3
6 = Memory
Preset 4
2 =
Background
Layer for
output 1
3 = Pip 1 Layer
for output1
Background
Layer for
output 2 in
matrix mode
8 = Audio
Output 1
9 = Audio
Output 2
PE_CROP_WIN_POS_H CH CH
Cropping window horizontal
position
Rd/Wr0 6553532768
Unit = percent ( 65535 = 100%
= : all cropping on the left )
0 = Current
preset
1 = Next preset
2 = Previous
preset
3 = Memory
Preset 1
4 = Memory
Preset 2
5 = Memory
Preset 3
6 = Memory
Preset 4
2 =
Background
Layer for
output 1
3 = Pip 1 Layer
for output1
Background
Layer for
output 2 in
matrix mode
8 = Audio
Output 1
9 = Audio
Output 2
