19
Group
Name CmdResp Description
Read
/
Write
Min
Value Max
value Default
value
Values Index #1 Index #2
SIG_FORMAT_LIST sL sL
Bit field of the fomats
compatible with the detected
format
Rd 0 255 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
0 = Bits 0 to 7
Slice
1 = Bits 8 to 15
Slice
2 = Bits 16 to
23 Slice
3 = Bits 24 to
31 Slice
4 = Bits 32 to
39 Slice
5 = Bits 40 to
47 Slice
SIG_SCANTYPE ss ss Input scan type Rd 0 3 0
0 = Progressive
1 = Interleaved, Top field first
2 = Interleaved, Bottom field first
3 = Segmented frame
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HTOTAL_THEORIC sH sH Total number of pixels per line Rd 0 655350 Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
