Analog Way PULSE LE - Ref. PLS200 Programmer's Guide User Manual
Page 5
5
Group
Name
CmdResp Description
Read
/
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
SYSTEM
DIESE
#
#
Request the retrieval of all the
variables
Rd/Wr0
1
0
READY
*
*
Ready Device Flag
Rd
0
1
0
0= Initialization in progress
1 = Ready
DEV
?
DEV MMS device type
Rd
79
79
79
79 = PLS-200
CONTROLS
UPDATER
yU yU
Device reboot for update
Rd/Wr0
255 0
1 then 254 => Reboot
FACTORYRESET
YR YR
Apply factory settings to the
device( except image settings )
Rd/Wr0
1
0
Auto reset
POSMEMORYRESET
YE YE Erase stored image settings
Rd/Wr0
1
0
Auto reset
CSTORE
YS YS
FLASH memory writing in
progess. Do not power off
Rd
0
1
0
0 = Free
1 = Flash writing in progress
LOCK
YK YK Device locking
Rd/Wr0
2
0
0 = No lock
1 = Locked menu
2 = Locked front panel
LCDBRIGHTNESS
YB YB Front panel display brightness Rd/Wr1
8
8
1, …, 8 = Brightness level, 12,5%
step
KEYBRIGHTNESS
Yb Yb
Front panel keys brightness
Rd/Wr10
100 100
1, …, 100 = Brightness level, 1%
step
TBAR_ENABLE
YD YD Enable disable T-BAR
Rd/Wr0
1
1
COPKIND
CK CK
Kind of slow in-progress
operation
Rd
0
6
0
0 = None
1 = Auto centering
2 = Auto setting
3 = StandBy
4 = Picture recording
5 = Reset to default factory
setting
6 = Reset User settings
COPPROGRESS
CP CP
Progress percent of the slow
operation
Rd
0
100 0
Percent : 0 to 100%
AXION
yA yA
Device is driven by Orchestra Rd/Wr0
1
0
0 = Device is not driven by ORC-
50
1 = Device is driven by Orc-50
AUTO_LOCK
YL YL
Forbide the use of a signal-less
input
Rd/Wr0
1
1
0 = Signal less input can be
selected
1 = Signal less input can not be
selected
AUTO_TAKE
YT YT
Automatic Take after an input
change
Rd/Wr0
1
0
0 = AUTO-TAKE Disable
1 = AUTO-TAKE Enable
