Group
Name CmdResp Description
Read
/
Write
Min
Value Max
value Default
value
Values Index #1 Index #2
PE_OPENING_TRANSITION_WAYoW oW
Layer opening transition
direction
Rd/Wr0 10 0
0 = Current
preset
1 = Next preset
2 = Previous
preset
3 = Memory
Preset 1
4 = Memory
Preset 2
5 = Memory
Preset 3
6 = Memory
Preset 4
2 =
Background
Layer for
output 1
3 = Pip 1 Layer
for output1
Background
Layer for
output 2 in
matrix mode
8 = Audio
Output 1
9 = Audio
Output 2
PE_OPENING_DURATION oD oD
Layer opening transition
duration
Rd/Wr0 255 10 Unit = 1/10s
0 = Current
preset
1 = Next preset
2 = Previous
preset
3 = Memory
Preset 1
4 = Memory
Preset 2
5 = Memory
Preset 3
6 = Memory
Preset 4
2 =
Background
Layer for
output 1
3 = Pip 1 Layer
for output1
Background
Layer for
output 2 in
matrix mode
8 = Audio
Output 1
9 = Audio
Output 2
