Analog Way PULSE LE - Ref. PLS200 Programmer's Guide User Manual
Page 20
20
Group
Name
CmdResp Description
Read
/
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
SIG_HTOTAL_MAXI
sM sM
Maximal number of pixels per
input line
Rd
0
655350
Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_WIDTH
sw sw
Input displayed pixel count
Rd
0
655350
Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HEIGHT
st
st
Input displayed line count
Rd
0
655350
Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HDCP
sn
sn
Input HDCP status
Rd
0
1
0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
