TALLY_TRIG

machine input tally
trigger

Rd/Wr 0

0 = no input
1 = Input 1 or analog Plug on
1st DVI or Source 1
2 = Input 2 or digital Plug on
1st DVI or Source 2
3 = Input 3 or 1st SDI Plug or
Source 3
4 = Input 4 or analog Plug on
2nd DVI or Source 4
5 = Input 5 or digital Plug on
2nd DVI or Source 5
6 = Input 6 or 2nd SDI Plug or
Source 6
7 = Input 7 or analog Plug on
3rd DVI or Source 7
8 = Input 8 or digital Plug on
3rd DVI or Source 8
9 = 3rd SDI Plug or Source 9
10 = analog Plug on 4th DVI or
Source 10
11 = digital Plug on 4th DVI or
Source 11
12 = 4th SDI Plug or Source 12
13 = analog Plug on HD15
number 5 or Source 13
14 = analog Plug on HD15
number 6 or Source 14
15 = analog Plug on HD15
number 7 or Source 15
16 = analog Plug on HD15
number 8 or Source 16
17 = Source 17
18 = Source 18
19 = Source 19
20 = Source 20
21 = Source 21
22 = Source 22
23 = Source 23
24 = Source 24
25 = Source 25
26 = Source 26
27 = Source 27
28 = Source 28
29 = Source 29
30 = Source 30
31 = Source 31
32 = Source 32
33 = Source 33
.
.
64 = Source 64

0 = Tally 1 output
1 = Tally 2 output
2 = Tally 3 output
3 = Tally 4 output
