TALLY
/GPIO
GPIO_MODE
GP GP
GPI or GPO mode
Rd/Wr 0
1
0
0 = 4 outputs mode
1 = 2 inputs and 2 outputs
mode
GPIO_TYPE
GT GT
GPIO or TALLY mode
Rd/Wr 0
1
1
0 = tally mode
1 = GPIO mode
0 = GPIO 1
1 = GPIO 2
2 = GPIO 3
3 = GPIO 4
GPIO_TRIG_EVENT
GE GE
GPIO trigger event
Rd/Wr 0
207
0
0 = no event
100 = TAKE (input event)
101 = TAKE when ready (input
event)
102 = Full status enumeration
(input event)
103 = Factory reset (input
event)
104 = Black all (input event)
105 = Freeze all (input event)
106 = AUTOSET (input event)
107 = AUTOCENTER all (input
event)
108 = Set default (input event)
109 = Next PRESET layout
(input event)
110 = Next recording mode
(input event)
111 = Standby or WakeUp
(input event)
200 = TAKE available (output
event)
201 = TAKE pending (output
event)
202 = Ready (output event)
203 = Full status enumeration
status (output event)
204 = HDCP conflict (output
event)
205 = Sequenced TAKE
(output event)
206 = TBar is ready (output
event)
207 = Output reference locked
(output event)
0 = GPIO 1
1 = GPIO 2
2 = GPIO 3
3 = GPIO 4
GPIO_STATUS
GS GS
GPIO status
Rd/Wr 0
1
0
0 = GPIO 1
1 = GPIO 2
2 = GPIO 3
3 = GPIO 4
