SET_HSIZE
Sw Sw
input signal horizontal
size
Rd/Wr 0
4096
2048
2048 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
7 = Input8
0 = Analog Plug
1 = DVI Plug
2 = SDI Plug
SET_VSIZE
Sh
Sh
input signal vertical size
Rd/Wr 0
4096
2048
2048 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
7 = Input8
0 = Analog Plug
1 = DVI Plug
2 = SDI Plug
SET_BRIGHTNESS
Sg
Sg
input signal brightness
Rd/Wr 0
255
128
128 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
7 = Input8
0 = Analog Plug
1 = DVI Plug
2 = SDI Plug
SET_CONTRAST
Sc
Sc
input signal contrast
Rd/Wr 0
255
128
128 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
7 = Input8
0 = Analog Plug
1 = DVI Plug
2 = SDI Plug
