Analog Way DI-VENTIX II - Ref. DVX8044 Programmer's Guide User Manual
Page 21
21
SET_ASPECT_RATIO_OUT
sB
sB
output picture aspect
ratio
Rd/Wr 0
3
2
0 = 1:1, not distorted, no zoom,
black bands or cropped
1 = centered, not distorted,
black bands added
2 = full screen, distorted, input
aspect ratio not preserved
3 = cropped, not distorted,
without black bands
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
7 = Input8
0 = Analog Plug
1 = DVI Plug
2 = SDI Plug
SET_OVER_SCAN
so
so
overscan
Rd/Wr 0
1
1
0 = underscan, 1 = overscan
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
7 = Input8
0 = Analog Plug
1 = DVI Plug
2 = SDI Plug
SET_CROP_HSTART
Lh
Lh
input signal H cropping
start
Rd/Wr 0
2048
0
0 = 0% = no left cropping
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
7 = Input8
0 = Analog Plug
1 = DVI Plug
2 = SDI Plug
SET_CROP_VSTART
Lv
Lv
input signal V cropping
start
Rd/Wr 0
2048
0
0 = 0% = no top cropping
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
7 = Input8
0 = Analog Plug
1 = DVI Plug
2 = SDI Plug
