Reference
REFREQUEST Xr Xr framelock type requested Rd/Wr 0 14 0
0 = Internal Reference
1 = (SDTV) Genlock input
2 = (HDTV) Genlock input
3 = Analog Input on DVI 1
4 = Digital Input DVI 1
5 = SDI 1 Input
6 = Analog Input on DVI 2
7 = Digital Input DVI 2
8 = SDI 2 Input
9 = Analog Input on DVI 3
10 = Digital Input DVI 3
11 = SDI 3 Input
12 = Analog Input on DVI 4
13 = Digital Input DVI 4
14 = SDI 4 Input
0 = Main Output
1 = Preview Output
2 = Recording
Output
REFSTATUS Xa Xa framelock type status Rd 0 14 0
0 = Internal Reference
1 = (SDTV) Genlock input
2 = (HDTV) Genlock input
3 = Analog Input on DVI 1
4 = Digital Input DVI 1
5 = SDI 1 Input
6 = Analog Input on DVI 2
7 = Digital Input DVI 2
8 = SDI 2 Input
9 = Analog Input on DVI 3
10 = Digital Input DVI 3
11 = SDI 3 Input
12 = Analog Input on DVI 4
13 = Digital Input DVI 4
14 = SDI 4 Input
0 = Main Output
1 = Preview Output
2 = Recording
Output
