Analog Way DI-VENTIX II - Ref. DVX8044 Programmer's Guide User Manual
Page 42
42
Logos
Frames
PMODE
PM PM
logo/frame mode
Rd/Wr 0
9
0
0 = Use Logo Frame mode
1 = Logo recording mode
2 = Live logo recording mode
3 = Frame recording mode
4 = Frame mask recording
mode
5 = Logo clear mode
6 = Frame clear mode
7 = Frame mask clear mode
8 = Complete frame, logo and
maskFrame clear mode
9 = Transfer Mode
PEXECUTE
PG PG
logo/frame control
Rd/Wr 0
1
0
start operation requested by
logo/frame mode. (recording or
erasure)(auto clear)
PABORT
PA PA
logo/frame recording
abort
Rd/Wr 0
1
0
(auto clear)
PSTATUS
PE PE
logo/frame control status Rd
0
5
0
0 = Free
1 = Logo/Frame Recalling
2 = Logo/Frame storing
3 = Logo/Frame Format and
output format not compatible
4 = Logo/Frame clearing
5 = Flash memory error
PFRAMES_VALID
PF
PF
frame available status,
bit field with
bit0=frame1 …
bit7=frame8,
bit8=maskFrame
Rd
0
1023
0
0 = no logo/frame available
PLOGOS_VALID
PZ
PZ
logo available status, bit
field with
bit0=logo1 … bit7=logo8
Rd
0
511
0
0 = no logo/frame available
PCAPTURE_LEFT
PL
PL
logo/frame horizontal
position
Rd/Wr 0
32767 0
in pixel
PCAPTURE_TOP
PT
PT
logo/frame vertical
position
Rd/Wr 0
32767 0
in pixel
PCAPTURE_WIDTH
PW PW
logo/frame capture
horizontal size
Rd/Wr 0
32767 400
in pixel
PCAPTURE_HEIGHT
PH PH
logo/frame capture
vertical size
Rd/Wr 0
32767 300
in pixel
PCAPTURE_LUMAKEY_TYPE
PY PY
logo/frame keying mode
Rd/Wr 0
1
0
0 = Black
1 = White
PCAPTURE_LUMAKEY_LEVEL
Pl
Pl
logo/frame luma key
level
Rd/Wr 0
255
0
0 = black, 255 = white
0 = Main Output
1 = Preview Output
2 = Recording
Output
0 = Black
1 = White
