Layer
Controls
COPY_LAYER_PRESET LP LP preset for layer copy Rd/Wr 0 6 0
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized Preset 1
4 = Memorized Preset 2
5 = Memorized Preset 3
6 = Memorized Preset 4
COPY_LAYER_FROM LF LF source for layer copy Rd/Wr 0 7 0
0 = Background Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
COPY_LAYER_TO LT LT destination for layer copy Rd/Wr 0 7 0
0 = Background Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
COPY_LAYER_CTRL LC LC
layer copy control (auto
clear)
Rd/Wr 0 1 0
0 = operation complete
1 = execute one layer copy
Settings
R_FLICK Rf Rf antiflicker level Rd/Wr 0 7 2 0 = no anti-flicker
0 = Main Output
1 = Preview Output
2 = Recording
Output
R_GAMMA Rg Rg gamma correction level Rd/Wr 5 40 10
gamma value in 1/10 (ex : 22
for 2.2)
0 = Main Output
1 = Preview Output
2 = Recording
Output
