Analog Way DI-VENTIX II - Ref. DVX8044 Programmer's Guide User Manual
Page 39
39
REFFORMAT
Xf
Xf
framelock signal name
status
Rd
0
41
0
0 = None
1 = Invalid
2 = unknown
3 = SDTV NTSC
4 = SDTV PAL
5 = SDTV SECAM
6 = SDTV BW
7 = SDTV 480i
8 = SDTV 576i
9 = EDTV 480p
10 = EDTV 576p
11 = HDTV 720p
12 = HDTV 1035i
13 = HDTV 1080i
14 = HDTV 1080p
15 = HDTV 1080sF
16 = CPU 640x480 VGA
17 = CPU 800x600 SVGA
18 = CPU 1024x768 XGA
19 = CPU 1280x960
20 = CPU 1280x1024 SXGA
21 = CPU 1364x1024 DILA 4/3
22 = CPU 1400x1050 SXGA+
23 = CPU 1600x900
24 = CPU 1600x1200 UXGA
25 = CPU 848x480 WVGA
26 = CPU 800x480
27 = CPU 1152x864
28 = CPU 720p RGB
29 = CPU 1280x768 WXGA
30 = CPU 1280x600
31 = CPU 1360x768 SWXGA
32 = CPU 1360x1024
33 = CPU 1366x800 SWXGA+
34 = CPU 1200x800
35 = CPU 1680x1050
WSXGA+
36 = CPU 1080p RGB
37 = CPU 1920x1200 WUXGA
38 = CPU 1920x1440
39 = CPU 1440x900
40 = CPU 2048x1080 2K 16/9
41 = CPU 1366x768
0 = Main Output
1 = Preview Output
2 = Recording
Output
REFFREQ
Xt
Xt
framelock rate status
Rd
0
65535 0
frequency in 1/100 Hz
0 = Main Output
1 = Preview Output
2 = Recording
Output
