Definitions
Item Function Options
API
Commands
Transport Mux
Rate
rate, in bps, that the multiplexed signal is being handed off max = 100000000
*.ECMD
TMR
Video Autofill
ties to Transport Mux Rate; uses non-audio packet space for
video On
Off
*. ECMD
VAF [x]
1 = on
0 = off
IP Destination
1-4 sub-label for items below. The sub-menu repeats four (4) times
for up to four multicasting IP destinations.
NONE none
Mode switches multicast function on and off
Off
Send *.ECMD
MMO
Multicast
Transmit IP
Address
IP Address on which a transport stream is transmitted
user-defined using
and
buttons*.ECMD MSIMulticast
Transmit Portport assignment used for transmitting a multicastuser-defined using
and
buttons
*.ECMD MSI
Multicast
Transmit Port
port assignment used for transmitting a multicast
user-defined using
and
*.ECMD
MSP
RTP
allows for sequence numbering and timing; editable if Multicast
Mode is set to 'Send' On
Off
*.ECMD RTP
TOS
Type of Service; selects the type of multicast that will forward
the packet
Normal
Minimize Cost
Maximize Reliability
Maximize Throughput
Minimize Delay
*.ECMD
TOS
TTL
Time-to-Live; specifies the number of iterations or
transmissions the packet can undergo before it is discarded
user-defined using
and
buttons *.ECMD TTL FEC ModeForward Edge Correction; selects on/off. When selected,
sends two FEC RTP streams in addition to a source RTP
stream enabling a receiver to reconstruct missing packets in
the source stream.On
Off
Available if RTP selected
'on' *.ECMD
ECRFEC Laffects the maximum burstpacket loss that can be recovered 4-20*.ECMD
ECR FEC Ddefines latency involved in burstrecovery 4-20*.ECMD
ECR CaptureEnable or disable encoder capture to file. If enabled, all
encoded content will be captured to file. If disabled, file capture
is turned off.On
Off*.ECMD
CCAwww.adtecdigital.com Pages: 1 … 20 21 22 23 24 … 104 wrong Brand wrong Model non readable See also other documents in the category Adtec digital Video: DPI-1200 (version 01.04.08U) Quick Start (2 pages) DPI-1200 (version 01.04.08U) Manual (58 pages) mediaHUB-HD 422 (version 1.01.10_M_2) Quick Start (2 pages) mediaHUB-HD 422 (version 1.01.10_M_2) Quick Start (67 pages) mediaHUB-HD 422 (version 1.01.10_M_2) Quick Start (68 pages) mediaHUB-HD 422 (version 1.01.10_M_2) Quick Start (2 pages) mediaHUB-HD 422 (version 1.01.10_M_2) Quick Start (2 pages) EN-80 (version 2.02.28) Quick Start (2 pages) EN-30 (version 1.02.02) Manual (59 pages) RD-30 (version 2.1.1) Quick Start (1 page) RD-30 (version 2.1.1) Manual (39 pages) mediaHUB-HD 422 (version 1.01.10_M_2) Quick Start (2 pages) mediaHUB-HD 422 (version 1.01.10_M_2) Quick Start (2 pages) mediaHUB-HD 422 (version 1.01.10_M_2) Quick Start (2 pages) YUV2QAM (version 01.02.01) Manual (46 pages) Soloist-HD Pro (version 02.07.09) Manual (77 pages) EN-91 / EN-91P (version 1.02.29) Quick Start (2 pages) DTA-3050 (version 6.02.14) Manual (94 pages) EN-20 (version 2.03.06) Manual (63 pages) mediaHUB-HD Pro (version 03.07.19) Studio Encoder Quick Start (2 pages) RD-60 (version 1.13.02) Quick Start (2 pages) edje-5110 (version 01.02.05) Manual (98 pages) eyeMonitor (42 pages) TBGS w/adManage (50 pages) Soloist 4111 (version 02.07.03) (1 page) EN-40 (version 2.02.24) (2 pages) mediaHUB (version 02.00.13) (24 pages) edje-5110 (version 01.02.05) Quick Start (2 pages) MAS & iptvManage (44 pages) AVS2 (5 pages) Sitemap
*.ECMD TTL
FEC Mode
Forward Edge Correction; selects on/off. When selected,
sends two FEC RTP streams in addition to a source RTP
stream enabling a receiver to reconstruct missing packets in
the source stream. On
Off
Available if RTP selected
'on'
*.ECMD
ECR
FEC L affects the maximum burstpacket loss that can be recovered 4-20
*.ECMD
ECR
FEC D defines latency involved in burstrecovery 4-20
*.ECMD
ECR
Capture
Enable or disable encoder capture to file. If enabled, all
encoded content will be captured to file. If disabled, file capture
is turned off.
On
Off *.ECMD
CCA
www.adtecdigital.com
