UM024502-1012 ZGATE Logging Page
ZGATE Embedded Security Development Kit
User Manual
81
ZGATE_add_ip_addr
Function Prototype
INT16 ZGATE_add_ip_addr( INT32 IP_Addr );
Parameters
IP_Addr The IP address to be added to the IP source address static filtering
list.
IP_Addr must be a 32-bit IPv4 address in little-endian (pre-
sentation mode) format (e.g., 192.68.1.15 would be represented
by the value
0xC0A8010F which, on the eZ80F91 MCU, is
stored in memory as 0x0F , 0x01 , 0xA8 , 0xC0 ).
Return Value
TRUE IP_Addr was successfully added to the IP Address static filtering
list.
FALSE IP_Addr already exists in the IP Address static filtering list, the
list is full or the IP Address filter is disabled.
Description
When the IP Address filter is operating in WHITELIST (forwarding) or BLACKLIST
(blocking) Mode, it extracts the source IP address from inbound IP packets and compares
the IP address to entries in the IP Address filtering list. If a match is found, the frame is
forwarded to ZTP if the filter operates in WHITELIST Mode and blocked from TCP if the
filter operates in BLACKLIST Mode.
This API is used to add an entry to the IP Address static filtering list. Entries cannot be
added to the list if the IP Address filter is disabled.
