ZGATE Shell Command Reference UM024502-1012
48
ZGATE Embedded Security Development Kit
User Manual
zg_config
Syntax
zg_config < add|remove|set>
Subcommands
add Adds one or more new values to the static filtering list corre-
sponding to
parameter . The add subcommand will print an
error message if the user attempts to add a value that is already on
the list.
remove Removes one or more new values to the static filtering list corre-
sponding to
parameter . The remove subcommand will print an
error message if the user attempts to remove a value that is not on
the list.
set Alters the specified ZGATE threshold filtering parameter.
Description
The zg_config command modifies ZGATE filtering parameters.
When the add or remove subcommands are specified, parameter must be one of the
following values: eth_frame , eth_addr , IP_Addr , IP_Prot , tcp_port or
udp_port .
Value(s) is a list of one or more items separated by spaces; the format and meaning of the
value(s) depends on the static filtering list targeted by
parameter .
eth_frame: Value(s) is an Ethernet frame type. Each item in the value(s) list
must be between 1 and 65535.
eth_addr: Value(s) is the Ethernet MAC address of a device that sends pack-
ets to ZTP. Each item in the value(s) list must contain six hexa-
decimal numbers (each between 0 and
0xFF ) separated by
colons; for example, "ab:cd:ef:01:23:45".
IP_Addr: Value(s) is the IPv4 address of a device that sends packets to ZTP.
Each item in the value(s) list must be in dotted decimal format
using 4 numbers (each between 0 and 255) separated by periods;
for example,
192.168.2.30 .
IP_Prot: Value(s) is an IP protocol number. Each item in the value(s) list
must be between 1 and 254.
tcp_port: Value(s) is a ZTP TCP port number. Each item in the value(s) list
must be between 1 and 65535.
