UM024502-1012 Integrating an Existing ZTP Application with ZGATE
ZGATE Embedded Security Development Kit
User Manual
21
– ZGATE000100ZCOG_Flash.ztgt
– ZGATE000100ZCOG_RAM.ztgt

To copy these files, hold down the Ctrl key on your keyboard and click each of the
three files. After all three files are highlighted, right-click and select Copy . Next, nav-
igate to the folder created in Step 2 and, in the whitespace of the folder window, right-
click and select Paste .
4. Launch ZDS II by navigating from the Windows Start menu to Programs → Zilog
ZDS II – eZ80Acclaim! → ZDS II – eZ80Acclaim! .
5. From the File menu in ZDS II, choose Open Project , and navigate to the folder cre-
ated in Step 2 .
6. Select the ZGATE_Demo_ZGATE000100ZCOG.zdsproj project and click Open . A
list of source files will appear in the Workspace panel.
7. In the Workspace panel, remove all of the files listed under Standard Project Files
except for the following 18 files:
– DataPer_Conf.c
– emac_conf.c
– ez80eval.c
– ez80Wh_Conf_ZDS.c
– F91PhyInit.c
– get_heap.asm
– httpAuth_conf.c
– ppp_conf.c
– rtc_conf.c
– RZK_Conf.c
– shell_conf.c
– snmp_conf.c
– tty_conf.c
– uart_conf.c
– ZFS_Conf.c
– ZTPConfig.c
– ZTPInit_Conf.c
– ZTPUsrDetails.c

To remove these files, click each of the files to be removed (one at a time) and press
the
Delete key.
8. In the Workspace panel, remove all of the files listed under Web Files by clicking each
of the files to be removed (one at a time) and pressing the Delete key.
