UM024502-1012 Installing the USB Smart Cable Driver
ZGATE Embedded Security Development Kit
User Manual
5
Windows 7 32/64 Systems
Observe the following steps to install the USB Smart Cable on a Windows 7 system.
1. Connect the USB Smart Cable to a USB port on your development PC. When the PC
detects the new hardware, it will display the Installing device driver software dialog.
2. Windows automatically searches for the driver; this process can take a few moments.
Because there is no option to terminate this search process, wait for the search to complete.
If the driver was previously installed, Windows will automatically install the USB
Smart Cable driver. If this is the case, skip ahead to
Step 9 . If Windows cannot find the
driver, close the search dialog and proceed to the next step.
3. From the Start menu, navigate via the Search Programs and files menu, and enter
Device Manager in the Search field to cause the Device Manager to appear in a list of
search results.
4. From this search list, click Device Manager to open the Device Manager dialog,
which presents a list of devices that operate on your PC. Find Other devices , toggle it
to view a sublist of additional devices, and right-click your mouse on USB Smart
Cable .
5. In the submenu that appears, click Update Driver Software... .
6. In the Update Driver Software – USB Smart Cable dialog that appears, click the
Browse my computer for driver Software option.
7. Click the Browse... button to browse to one of the following driver directories,
depending on the configuration of your PC.
On 32-bit Windows 7 systems, navigate to:
II Installation Directory>\device drivers\USB\x32

II Installation CD>\device drivers\USB\x32
On 64-bit Windows 7 systems, navigate to:
II Installation Directory>\device drivers\USB\x64

II Installation CD>\device drivers\USB\x64
8. Click Next to install the driver. On 32-bit: Windows systems, a security dialog will
appear; select Install this driver software anyway .
9. Click Close after the Wizard finishes the installation.
Windows Vista 32/64 Systems
Observe the following steps to install the USB Smart Cable on a Windows Vista system.
1. Connect the USB Smart Cable to a USB port on the development PC.
