The ZGATE Embedded Security Development Kit
UM024502-1012
20
ZGATE Embedded Security Development Kit
User Manual
ZGATE first checks for the presence of the ZGATE user configuration file,
zg_rules.usr
, in ZFS. If this file is present, ZGATE uses the configuration rules in this
file. If this file is not present, ZGATE next looks for the ZGATE default configuration file,
zg_rules.def
, in ZFS. If this default file is present, ZGATE uses the configuration rules
in this file.
If neither configuration file is present (or if ZFS support is not included in the ZTP appli-
cation), ZGATE uses the configuration rules defined in the
ZGATE_Conf.c
file that is
compiled and linked to the ZTP application. If the
ZGATE_Conf.c
file is modified, it is
necessary to rebuild and download the project.
If ZFS is used and the
zg_rules.usr
file becomes unusable, a next-level static configu-
ration file can be recovered. For example, the
zg_rules.usr
file could become unusable
if the IP address filter is configured for WHITELIST filtering, but no IP addresses are
added to the filtering list. In this instance, ZGATE will block all IP packets from reaching
ZTP, effectively disabling all network communication.
This recovery of the next-level static configuration file can be performed using either of
the following two methods:
•
Using a browser, navigate to the Startup Settings page of the ZGATE Demo program
and click the
Use Default
button.
•
Issue the
zg_restore
command on the ZTP console.
Either method will erase the
zg_rules.usr
file and cause ZGATE to boot with the set-
tings defined in the
zg_rules.def
ZFS file (if present) or the settings defined in the
ZGATE_Conf.c
file that is linked to the ZGATE Demo program.
Integrating an Existing ZTP Application with ZGATE
ZGATE support can be added to any ZTP application using the following procedure:
1. From the
Start
menu on a Windows PC, click
Computer
and navigate to the
Sample
Programs
folder of the ZTP installation. By default, this folder will be located in the
following filepath:
2. Create a new folder in the Sample Program folder by right-clicking in the display win-
dow and selecting
New…
, then
Folder
. Enter an appropriate name for the folder; for
example,
MyZgateDemo
.
3. Navigate to the ZGATE_Demo folder and copy the following three files to the folder
created in
–
ZGATE_Demo_ZGATE000100ZCOG.zdsproj
