The ZGATE Embedded Security Development Kit UM024502-1012
8
ZGATE Embedded Security Development Kit
User Manual
To launch the Device Manager on Windows 7 systems, launch the Start menu, enter device
manager in the Search programs and files field, and press the Enter key.


To open the Device manager on earlier Windows systems, navigate via the following path:


Start
→
Control Panel
→
System
→
Hardware
→
Device Manager
→
Ports (COM& LPT)
Connecting the ZGATE Embedded Security Development
Board to your PC
Observe the following procedure to connect the ZGATE Embedded Security Board to
your PC.
Disconnect or turn off the power to the ZGATE Embedded Security Development Board
before connecting or disconnecting the USB Smart Cable.
Figure 2. A Successful USB-to-UART Driver Installation
Note:
Caution:
