UM024502-1012
ZGATE Embedded Security Development Kit
User Manual
1
The ZGATE Embedded Security
Development Kit
ZGATE technology incorporates the eZ80F91 MCU and Zilog’s full-featured TCP/IP
stack with a world-class embedded firewall. This highly-configurable firewall protects the
ZTP networking layers from attack by discarding suspicious packets before they reach
ZTP and your embedded application. The ZGATE firewall includes a static packet filter-
ing engine that filters packets according to user-defined configuration rules and a stateful
packet inspection engine that can automatically filter suspicious packets based on unusual
activity. Additionally, select ZGATE products include threshold-filtering mechanisms that
can minimize the affect of packet floods.
Zilog’s ZGATE Embedded Security Development Kit, part number ZGATE000100ZCOG,
provides a general-purpose platform for creating a design based on this eZ80F91 micro-
controller, which has been preprogrammed with a ZGATE security code. The eZ80F91
MCU is a member of Zilog’s eZ80AcclaimPlus! product family, which offers an on-chip
EMAC and Flash memory.
This document provides instructions for setting up and configuring your ZGATE Embedded
Security Development Board and includes schematic diagrams and a discussion of Board
features and ZDS II.
The first sections of this document guide you through the following tasks:
•
Download and Install the ZDS II Software and Documentation on page 4
•
Installing the USB Smart Cable Driver on page 4
•
Installing the FTDI USB-to-UART Driver on page 7
•
Connecting the ZGATE Embedded Security Development Board to your PC on page 8
•
Starting the ZGATE Demo Sample Program on page 11

Further details, including memory configurations, jumper settings and a listing of sample
projects can be found in
Appendix A. ZGATE Embedded Security Development Board on
page 105.
Figure 1 shows an image of the ZGATE Embedded Security Development Kit.
