Controls, Indicators and Connections
5) [H/V DELAY] Button/Lamp
- Used to check horizontal and vertical sync simultaneously by moving the screen
up/down/left/right.
- In this mode, the brightness of image automatically increase for easy verification of synchro-
nized signals.
6) FREEZE
- Captures still frame on-screen.
7) OUTPUT MODE
- Selects luminance range in SDI MODE between FULL (255) and NORMAL (235).
8) DITHERING
- Toggles 10bit Dithering On/Off.
9) FILTER
- This item toggles the 4:4:4 video processing filter On/Off.
- Filter eliminates ringing artifacts in 4:2:2 sources, please set this filter On or Off.
10) FORCE psf
- This item forces psf mode for psf signals, overriding the automatic psf detection.
- If this feature is turned off, the unit checks for the psf signal first, then searches for the
remaining modes.
11) COLOR TEMP
- This item controls color temperature and allows instant access to preset color temperature
settings.
12) HD DISPLAY
- Controls the display ratio of HD display. 16:9, 1.85:1, 2.35:1
[MENU] Button
- Used to activate the OSD menu.
[DOWN/BRIGHT] Button
- Used to move down within the menus during OSD menu activation and also to decrease the
value of the selected feature.
- May also be used to control the BRIGHT value during OSD menu inactivation. Use UP/DOWN keys
to adjust BRIGHT value.
[UP/CONTRAST] Button
- Used to move up within the menus during OSD menu activation and is also used to increase
the value of the selected feature.
- It may also be used to control the CONTRAST value during OSD menu inactivation. Use UP/DOWN
keys to adjust CONTRAST value.
