Menu Contents

[9] SYSTEM

USER CONFIG SET

- This item saves three user configurations.

- Available modes are USER1, USER2 and USER3.

- Effective items for each USER1, USER2 and USER3 settings are MARKER, CENTER MARKER, SAFETY

AREA, MARKER MAT and MARKER COLOR of MARKER 1/2 Menu, BRIGHT, CONTRAST, CHROMA,

PHASE and APERTURE of [PICTURE] 1/3 menu.

LOCK NUMBER

- Factory serial number of the product.

LOCK ENABLE (optional)

- This item is used to enable the 3G format.

- After entering the lock enable code, power cycle the unit. 3G FORMAT selection in Video Menu

will be activated and this LOCK ENABLE selection will be deactivated.

OSD DISPLAY

- This item controls the OSD display time.

- Available values are 3 SEC, 20 SEC and CONTINUE.

OSD POSITION

- This item controls the OSD position.

- OSD display on the top left position of quad screen.

- Available positions are Center, Top-Left(L-T), Top-Right(T-R), Bottom-Left(L-B) and Bottom-

Right(R-B).

INTERNAL PATTERN

- This item generates internal white pattern. The white level select between 0% and 100% (Per 5%

increase or decrease).

SET DEFAULT

- User can use the SET DEFAULTS feature to initialize the values to 0 of BRIGHT, CONTRAST, PHASE

and CHROMA of the monitor.

PAGE I >> PAGE II

USER CONFIG SET

LOCK NUMBER yyyyyyyy

LOCK ENABLE --------

OSD DISPLAY CONTINUE

OSD POSITION CENTER

INTERNAL PATTERN OFF

SET DEFAULT

Below is the description for each function of the SYSTEM menu.

SDI A LUM-560W 1080/60p
