Controls, Indicators and Connections

Multi F

orma

t L

CD M

onit

or

10

[ENTER] Button

- Used to confirm a chosen value (or mode).

- May also be used to control the VOLUME value during OSD menu inactivation. Use UP/DOWN

keys to adjust VOLUME value.

[OPERATE] Lamp

- Indicates condition and power status of unit.

- Light turns off when the power is disconnected.

- Standby mode is indicated by a red LED light.

- Normal (active) mode is indicated by a Green LED light.

- Restores to previous state when monitor power turns off and comes back on.

[POWER] Button

- Used to turn power on and off.
