Other Functions

[2] SCAN BUTTON (APPLY AFTER F2~F5 KEY MAPPING)

1. Press [SCAN] button continuously to activate various scan modes (selected sequentially) :

SDI, DVI,HDMI : OVER SCAN -> ZERO SCAN -> UNDER SCAN -> 2:1 SCAN -> 1:1 SCAN -> FIT WIDTH

2. SCAN MODE is not supported in SINGLE MODE.

3. The following represents the different types of scan mode. When a scan mode is selected, display

skips the next mode if its required condition is not met.

- OVER SCAN : Zooms in/out of the image to 96% of its original size without changing the aspect

ratio.

- ZERO SCAN : Zooms in/out of the image without changing the aspect ratio.

- UNDER SCAN : Zooms in/out of the image without changing the aspect ratio. Also, displays the

data at the top of the horizontal blanking block.

- 2:1 SCAN : Magnifies the original image two times. This feature is available only when the size of

the original image is ½ size or smaller than the screen size.

- 1:1 SCAN : 1:1 pixel mapping of original image.

- FIT WIDTH : In SD mode, zooms in to fit width of the original image to the width of the screen

without changing the aspect ratio.

This product supports various scan modes.

Press [SCAN] button on the front of the monitor to activate different scan modes. Key mapping

can be set in the MENU.
