Menu Contents

Multi F

orma

t L

CD M

onit

or

20

MARKER MAT

- This item darkens the area of the outside of MARKER.

- Adjusts mat opacity between OFF(0) and (7).

MARKER COLOR

- This item controls the color of the MARKER lines.

- Available colors are white, gray, black, red, green and blue.

MARKER THICKNESS

- This item controls the thickness of the MARKER lines.

- The degrees of thickness are between (1) and (7).

USER MARKER H1

- This item controls the position of the first user defined horizontal marker line.

- Marker option USER needs to be selected.

USER MARKER H2

- This item controls the position of the second user defined horizontal marker line.

- Marker option USER needs to be selected.

USER MARKER V1

- This item controls the position of the first user defined vertical marker line.

- Marker option USER needs to be selected.

USER MARKER V2

- This item controls the position of the second user defined vertical marker line.

- Marker option USER needs to be selected.

SDI A LUM-560W 1080/60p

PAGE I >> PAGE II

USER MARKER H1 MIN

USER MARKER H2 MIN

USER MARKER V1 MIN

USER MARKER V2 MIN
