13

Menu Contents

[1] PICTURE

BRIGHT

- This item controls the degree of brightness between MIN(-100) and MAX(100).

CONTRAST

- This item controls the contrast ratio between MIN(-100) and MAX(100).

CHROMA

- This item controls saturation between MIN(-50) and MAX(50).

PHASE

- This item controls PHASE value (tone) between MIN(-50) and MAX(50).

- Only available in COMPOSITE 1/2/3 and S-VIDEO modes.

- Phase control in DVI ANALOG mode is between MIN(0) and MAX(63).

APERTURE

- This item controls the picture sharpness between MIN(-1) and MAX(5).

- Noise reduction activates only if the value is set at -1.

BRIGHT 0

CONTRAST 0

CHROMA 0

APERTURE 0

Below is the description of the PICTURE menu.

SDI A LUM-560W 1080/60p
