DVI DIGITAL Support Resolution
Multi F
orma
t L
CD M
onit
or
29
SDI A LUM-560W 1080/60p
DVI DIGITAL SUPPORT RESOLUTION
Resolution Frequency
640 × 480 60Hz, 75Hz
800 × 600 60Hz, 72Hz, 75Hz
1024 × 768 60Hz, 70Hz, 75Hz
1366 x 768 60Hz/75Hz
1280 x 1024 60Hz/75Hz
1600 x 1200 60Hz
1920 X 1080 60Hz
SMPTE-274M 1080i (60/59.94)
SMPTE-425M 1080p (23.98/24/50/59.94/60)
SMPTE-296M 720p (60/59.94)
SMPTE-125M 480i (59.94), 480p(59.94)
DVI DIGITAL Graphic mode support resolution :
DVI DIGITAL Video mode supports the following input signals :
DVI DIGITAL mode is separated into Graphic mode and Video mode.
In DVI DIGITAL mode, ZERO scan must be selected for normal function.
If the input image is in non-wide mode, press ASPECT button to change to wide display.
