Controls, Indicators and Connections

REAR

[REMOTE] (RJ-45)

- Provides connection to control equipment for external monitor control.

- Features can be changed in the REMOTE(1/2) section of OSD menu.

[RS422 IN/OUT] (RJ-45)

- Used to control the monitor with protocol provided by TVLogic or to support TSL protocol.

[RS232] (D-SUB 9Pin)

- Used for ethernet based firmware updates and automatic alignment.

[DVI-A,B,C,D]

- Signal input terminal for DVI A,B,C,D signal.

[HDMI-A,B,C,D]

- Signal input terminal for HDMI A,B,C,D signal.

[SDI-A,B,C,D] (BNC)

- 3G/HD/SD SDI signal input terminal for SDI A,B,C,D signal.

[Audio in & out] (PHONE JACK)

- Select the left/right Audio Disembedder signal output or HDMI input signal or external stereo

signal is output through the phone jack

[Ethernet & USB]

- Ethernet and USB port for easy firmware update.

~ AC IN

- 100 ~ 240V AC 50/60Hz

Warning!!

When using the product, make sure to connect the GND first before connecting the input signal

line. The unit may not operate properly if the input line is connected before the GND is connected.
